Tunnel conveyor belt type microwave drying and sterilizayion machine for soybeans

Tunnel conveyor belt type microwave drying and sterilizayion machine for soybeans

1.Operating principle:
microwave source adopts continuous microwave magnetron as its microwave oscillation source. The continuous magnetron is a kind of cross-field microwave radio tube, the direct current field and

the stationary magnetic field are vertical. The anode of the magnetron is a complex system of resonance. The anode block consists of many litLDe resonant cavity. Between them there is inductance coupling, so theanode block is the crossover network of microwave. The electron eradiated from the cathode of the magnetron will firsLDy be affected by the direct current field and curl like an angle. While the electrons are moving from the cathode to the anode, the contrail of their movement is like a LDing vibration. Under the condition of synchronism between high frequency field and electron cloud, the electron contrail will rise toward the anode direction and form electron spoke. Among the spoke, while the electrons are carrying through synchronistically, they will change the potential energy into high frequency energy and increase the high frequency breadth. After themagnetron is started, the direct current which is instored in the resonance cavity will be changed into superhigh frequency energy, finally, microwave source of enough power will exported through wave-guide.

2.Structure&characteristics:

The multifunction microwave sterilizing and drying equipment is the upgrading and updating products

of the common continuous microwave one. it may adopt cutting-edge technical means according to

customers requirement, collocated with PLC human-machine interface auto-control system, it is

convenient to set arts and crafts parameters like temperature, power, speed, time and failure warning.Inside the human-machine interface, the equipment running mimic diagram, the instructions

of equipment operation, the failure maintenancem, knowledgereading, the enterprises brief introduction is available for the customers reference.

We can manufacture the Non-standard equipment according to the requirement of customers

microwave drying and sterilization machine for Chinese traditional medicine

3.Microwave olive leaves dryer features:

1, Fast drying , just need 3~5 minutes .

2,Save energy and efficiency.

3. Continuous conveyor belt type , can dry olive leaves continuously , continuous production;

4. Also have sterilization function during drying process .

5. Easy to operate, just need 2~3 workers.

6. Cover less area . We also can specially design according to your work yard area.

4.Technical parameter:

Power 380V icrowave frequency 2450±50MHz

5.Reference pictures:

Please contact me to talk more details!

If you interesting in Tunnel conveyor belt type microwave drying and sterilizayion machine for soybeans ?kindly ask me, Shandong industrial microwave oven can give technical support and service.
Please metioned below information in your inqury.
1.What's your raw material? How about the form of your products?
2.How much moisture content before drying and after drying?
3.How many input and output capacity per hour?
Once confirm above details,we can provide a suitable solution for you.

In addition,Shandong industrial microwave oven not only manufacture Agricultural and Sideline products dryer ,but also have oil press and refined oil equipment for peanut, soybean, rapeseed, cottonseed, sunflower, sesame, animal,grape seed, acer truncatum, peony seed, walnut, hemp seed, pine, tea seed, papaya, milk thisLDe seed, and other special material.

Expect to help you and cooperate with you in near future.
