Tunnel Continuous Conveyor Type Microwave Wood Drying Machine

If you interesting in Tunnel Continuous Conveyor Type Microwave Wood Drying Machine ?kindly ask me, Shandong industrial microwave oven can give technical support and service.
Please metioned below information in your inqury.
1.What's your raw material? How about the form of your products?
2.How much moisture content before drying and after drying?
3.How many input and output capacity per hour?
Once confirm above details,we can provide a suitable solution for you.

In addition,Shandong industrial microwave oven not only manufacture Microwave equipment ,but also have oil press and refined oil equipment for peanut, soybean, rapeseed, cottonseed, sunflower, sesame, animal,grape seed, acer truncatum, peony seed, walnut, hemp seed, pine, tea seed, papaya, milk thistle seed, and other special material.

Expect to help you and cooperate with you in near future.

Contact Shandong industrial microwave oven
Miss Jessica
Skype:leaderfoodmachine1
Tel:+8615964025360 (WhatsApp&Wechat)
Email:[email protected]

Specifications

1.heating rapidly and uniformity
2.energy saving and efficient
3.CE

Tunnel Continuous Conveyor Type Microwave Wood Drying Machine

Application Range (for wood products):

Mainly used for bamboo,wood(pencil board,wood floor,hanger etc),old mahogany,ebony,cherry

wood,basLDood,birch,teak,oak,boxwood,pear wood,beech,mulberry,serpentine wood,birch,maple

spruce,pine,hemlock,cercis,jacaranda,sophora japonica,maple wood,poplar,maple,endospermum

chinense,holly,ginkgo biloba wood,camphorwood,fir drying insecticide.

Techinical parameters:

Model	JN-50
Microwave Output Frequency	2450±50MHz
Microwave input apparent power	≤70KVA
Microwave output power	≥50KW
Microwave power adjustment range	0-50KW(adjustable)
Ambient temperature	-5-40°C
Dehydrate	50kg/h
Relative humidity	≤80%, Surrounding environment:no corrosive gas, conductive dust and explosive gas
Overall dimension(L*W*H)	11810*1440*1750 mm
Transmission speed	0-10m/min(adjustable)
Height of the inlet and outlet	60 mm
Microwave leak	accord with a country GB10436-89 standards(5 mwcm^2)
Equipment safety	accord with GB-5226Electrical safety standard accord with a country GB16798-1997 Food machinery health security index

Machine features:

1. Improve the quality of products,no cracking,no shrink,no deformation,insect-resistant;

2. Drying and insecticidal proceed at the same time,good effect;

3. Drying fast,low energy consumption,lower the cost,increase efficiency;

4. No environmental pollution,particularly applicable to the production process factories which located in the strict environmental requirements area;

Drying and sterilizing features:

1. The equipment is made of high-quality 304# stainless steel,fully meet with medicine machinery requirements;

2. Microwave leak:accord with a country GB10436-89 standards(≤5 mw/cm²);

3. Control system: PLC control interface or press-button control;

4. Adopt high-quality Panasonic magnetron,long life,best effect;

5. Low-temperature drying and sterilization,keep material character perfect,keep the ingredient.

General Description

1.Dry temperature:adjustable

2.Type of Feeding:continuous

3.Type of Control:control panel

The Features of Design

1.Transmission System:

a. Speed of Conveying belt is adjustable.

In the transmission system, it applies frequency-converting control of speed, worm gear reducer.

b. The conveyor belt is Teflon Belt,special for microwave.

c. The deviation of belt is adjusted with Hand-movement.

2. The body of the Tunnel

a.The body of the microwave tunnel is made of Stainless Steel. In side there is one set of humidity extraction system to extract the humidity after heating.

b. To be safe, there is Automatic Power-off device while open the door of the machine.

c. The protecting case of Magnetic-pipe and transformer is made of stainless steel. On top there is one set of Heat extraction system to extract the heat energy generated by

working of machine.

d.The frame of machine is made of Stainless Steel pipe ,others is made of cold-rolled sheet painted.

e.One set of infrared thermometric is installed at the outlet of the tunnel to measure the temperature.

3.The controlling system

a. On the outside panel there are frequency converting speed controller, emergency stop button, Start, Stop buttons,

b. All the controlling components will be installed into one controlling box, which is at the entrance of the machine.

c.Ordinary button control system,.

d.The microwave power can be adjusted by choosing in the display text.

e. Every microwave source is an independent unit.If one is broken, the machine will not be prevented from running.

f. Every magnetron has an overheating protection device.

Pictures:

If you are interested in our equipment- Continuous type microwave wood drying machine ,please feel free to contact us.Welcome to your sooner inquiry.

Thank you
